Optoelectronic Encoder: Optical Rotary Encoder NPN Open Circuit Incremental Encoder The optoelectronic encoder is a high-precision optical encoder that uses light beams to convert rotary motion into digital signals. This encoder is available in various resolutions, including 1024 pulses per revolution (p/r), 600 p/r, and 360 p/r. The single-phase version with 600 pulses per revolution is particularly noteworthy. Using two phases, A and B, enables frequency doubling, allowing for up to 2400 pulses per revolution. Technical details: - Power supply: The encoder requires a DC voltage in the range of 5 to 24 volts, which makes it flexible for different applications. - Shaft: The shaft has a size of 6 x 13 mm (0.23 x 0.51 inches), perfect for use in compact machines. - Encoder size: With dimensions of 38 x 35.5 mm (1.49 x 1.39 inches), the encoder offers a compact solution for many applications. - Output: The encoder features an AB 2-phase output provided as a rectangular orthogonal pulse circuit. The outputs are designed as NPN open collectors and require careful handling to avoid damage to the triode outputs. - Maximum mechanical speed: The encoder can reach up to 5000 rpm and thus supports high speeds. - Response frequency: It offers a response frequency of 0 to 20 kHz, which enables fast signal processing. - Cable length: With a cable length of 1.5 meters, the encoder offers sufficient space for installation. Important note : The A and B phase outputs must not be connected directly to VCC as this may damage the triode outputs. Overall, this optoelectronic encoder provides a reliable and precise solution for applications requiring accurate rotary positioning. Power source: DC5-24V Shaft: 6 * 13 mm/0.23*0.51" Size: 38 * 35.5 mm/1.49*1.39" Output: AB 2 phase output rectangular orthogonal pulse circuit, the output for the NPN open collector output type Maximum mechanical speed: 5000 rpm Response Frequency: 0-20kHz Cable length: 1.5 meters Connection: Green = A phase, White = B phase, Red = Vcc Power + Black = V0 Scope of delivery : 1 x piece

Read more less

Steering angle: 180 degrees Control by remote control Current: 4.8V/470mA 6.0V /650mA Load current: 4.8V/750mA 6.0V/950mA Dead band:2usec Lifespan:>15000 times without load Moving angle: 60 ° ± 10 ° Stick Type: MOS stick Motor type: Cored motor Potentiometer type: Direct drive Signal Booster Type: Digital Size: 40.5X20.2X40.3mm Weight: 62g (without accessories) Ball bearings: 2BB Gearbox Material: Metal Gearbox Case Material: PA66+fiber40% Wire length: 260mm Connector type: 26AWG,JR connector Brown Wire: Negative Red wire: Positive Orange wire: signal Application: RC car, RC airplane, helicopter 25KG servo: Storage temperature range: -30 °C ~ 80 °C Operating temperature: -25 °C ~ 70 °C Temperature range: -25 °C ~ 70 °C Humidity range: 65% ± 10% Size: 40.0*20.5*40.5mm Weight: 56g ± 2g Gearbox Type: 5 Metal limit angle: 360 ° bearing: 2BB Head gear spline: 25T Diameter: 5.9mm Head type: plastic, POM Case: Engineering plastic (PBT)+ aluminum alloy Connector wire: 320mm ± 5mm Motor: Carbon brush motor Steering angle: 180 degrees Control by remote control Voltage: 4.8 V-7.2 V no load speed: 0.18 sec/60 °-0.14 sec/60 ° Current: 140mA - 200mA Peak Torque: 23.5kg.cm-26.8kg.cm Current: 2600mA ± 10% - 3400mA ± 10% Voltage range: 4.8-7.2 V Command Signal: Pulse width change Amplifier Type: Digital Controller Pulse wide range: 500 ~ 2500usec Neutral position: 1500usec Running degree: 180 ° ± 3 ° (when 500 ~ 2500usec) Dead band width: 5 usec rotating direction counterclockwise: (when 1000 ~ 2000usec) Attention !!! 360° Servo: Rotate continuously either left or right 35KG servo: Operating voltage range: 4-8.4 V Operating speed (6 V): 0.238 seconds/60 ° (42 rpm) Operating speed (7.4V): 0.192sec/60 ° (52RPM) Stall torque (6V): 28.8kg/cm Stall Torque (7.4V): 35.5kg/cm Running current no load (6V): 150mA Running current without load (7.4V): 180mA Stall current at blocking (6V): 3.2a Stall current when locked (7.4V): 3.9A No-load current (at standstill): 6mA Rated torque (6V): 9.5kg.cm Rated torque (7.4V): 11.8kg cm Rated current (6V): 1000mA Rated current (7.4 V): 1200 mA Control specification: Control: PWM (pulse width change) Pulse width range: 500-2500 μsec Neutral position: 1500 μsec Degree of travel: 180 ° (at 500-2500 μsec) Dead band width: ≤ 4 μsec Direction of rotation: counterclockwise (at 1500-2500 μsec) Control: PWM (pulse width change) Pulse width range: 500-2500 μsec Neutral position: 1500 μsec Degree of travel: 180 ° (at 500-2500 μsec) Dead band width: ≤ 4 μsec Scope of delivery : 1 x piece 25KG / 3.5KG

Read more less

The JGA25-370 is a powerful DC motor available in various voltages of 6V, 12V, and 24V. Its compact design and high efficiency make it an ideal choice for a wide range of applications, from model making to automated systems and industrial machinery. Technical features The JGA25-370 features a robust construction and durable materials. With high torque and consistent power output, this motor offers excellent value for money. The various voltage options allow users to tailor the motor to specific requirements. The integrated gear unit further increases torque while maintaining controllable speed. This makes it particularly suitable for applications requiring precise control and high loads. Areas of application Thanks to its versatility, the JGA25-370 finds application in many areas. In model making, it is often used for remote-controlled vehicles or robots. It is also used in automation technology, for example, in conveyor belts or automated locking mechanisms. Furthermore, this motor is ideal for DIY projects that require a reliable drive. Scope of delivery : 1 x piece

Read more less

Product description: 2838 Massage bed vibrator with micro vibration motor The 2838 massage bed vibrator is an innovative device designed for the targeted application of vibration therapy and massage. It is suitable for use in both professional facilities and for home use. With a compact design and powerful specifications, this vibration massage motor offers a variety of benefits. Technical specifications - **Rated voltage**: The motor can be operated with either 12V or 24V, making it flexible for different applications. - **Working current**: With a working current of only 0.4 A, the motor is energy efficient and does not place unnecessary strain on your power supply. - **Working speed**: The motor reaches impressive working speeds of up to 5000 rpm, so it can effectively relieve even stubborn tension. - **Maximum power**: With a maximum power of 6 watts, the motor can operate even during extended use without the risk of overheating. - **Product size**: With dimensions of 93 mm (length) x 64 mm (width) x 33 mm (thickness), the vibrator is compact and can be easily integrated into various massage beds. wiring The 2838 massage bed vibrator is equipped with a No. 22 sheathed wire that is approximately 1 meter long. It is connected via a DC 5.5 × 2.1 female plug, which facilitates installation and replacement of the device. Area of ​​application e This micro vibration motor is ideal for various applications, including: - **Massage baths**: Comfort and relaxation for your customers. - **Pet feeding devices**: Promote a quiet environment during feeding. - **Home use**: Ideal for personal massages to relieve muscle tension. Overall, the 2838 massage bed vibrator combines innovative technology with practical applications, making it a valuable addition to any massage and therapy environment. Specifications for 2838 Vibrator : Rated voltage: DC12V / 24V Working current: 0.4 A Working speed: 5000 rpm Maximum power: 6 watts Product size: 93 mm (length) x 64 mm (width) x 33 mm (thickness) Wiring: No. 22 sheathed wire, the longest is about 1 meter, with DC 5.5 × 2.1 female plug Specifications for 2430 Vibrator : Rated voltage: DC12V Working current: 0.35 A Working speed: up to 4500 rpm Maximum power: 3 watts Product size: 75 mm (length) x 50 mm (width) x 29 mm (thickness) Wiring: No. 22 sheathed wire, the longest is about 1 meter, with DC 5.5 × 2.1 female plug Material: Plastic Color: Blue/Gray Scope of delivery : 1 x piece
